IPC-HDBW7442H-Z Series AI CCTV Dome Cameras Face Recognition

IPC-HDBW7442H-Z Series AI CCTV Dome Cameras Face Recognition

    Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF,EXW,FCA
    Min. Order: 1 Set/Sets
    Delivery Time: 15 Days
    Packaging: netual packing ,color packing or customized packing, paper box , foam and plastic inside
    Productivity: 50000 sets per week
    Brand: DZNEVO
    Transportation: Ocean,Land,Air
    Place of Origin: Shenzhen
    Supply Ability: 200000 per month
    Certificate: ISO9001 CE FCC SGS
    HS Code: 85299049
    Port: Shenzhen,Shanghai,Hangzhou

Basic Info

Model No.: IPC-HDW7442H-Z

Product Description

Product Description



4MP AI IR Dome Network Camera

4MP, 1/1.8" CMOS image sensor, low illuminance, high image definition

Max outputs 4MP (2688×1520) 50 fps/60 fps

H.264&H.265 coding, high compression ration

Wide dynamic, day/night, 3D noise reduction, AWB, HLC, BLC

ROI, SVC, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

With deep learning algorithm, it supports people counting, face recognition, perimeter protection etc

24V AC/PoE/12V DC power support

Five streams for three-channel HD video

IP67, IK10 protection grade


Product Details

HDW7442H

Specification


Camera IPC-HDBW7442H-Z Series
Image Sensor 1/1.8” 4Megapixel progressive CMOS
Effective Pixels 2688 (H) × 1520 (V)
ROM 16 GB/ZFR/Z4FR
4GB/Z4/Z
RAM 2 GB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s
Min. Illumination 0.001 Lux F1.2/ZFR/Z
0.001 Lux F1.6/Z4FR/Z4
IR Distance Distance up to 40m (131.23 ft)/ZFR/Z
Distance up to 80m (262.5 ft)/Z4FR/Z4
IR On/Off Control Auto
IR LEDs Number 3(IR LEDs)
Pan/Tilt/Rotation Range Pan: 0°–355°
Tilt: 0°–95°
Rotation: 0°–380°
Lens
Lens Type Motorized vari-focal
Mount Type Module interface
Focal Length 2.7–12 mm/ZFR/Z
8 mm–32 mm/Z4FR/ZR
Max. Aperture F1.2/ZFR/Z
F1.6/Z4FR/ZR
Field of View Horizontal: 114°(W)–47°(T) /ZFR Horizontal: 111°(W)–47°(T) /Z Vertical: 59°(W)–27°(T)/ZFR Vertical: 59°(W)–26°(T)/Z Diagonal: 141° (W)–55°(T)/ZFR Diagonal: 135° (W)–51°(T)/Z
Horizontal: 40° (W)–15°(T)/Z4FR/Z4 Vertical: 23° (W)–9° (T)/Z4FR/Z4 Diagonal: 46° (W)–18° (T)/Z4FR/Z4
Iris Type Auto aperture
Close Focus Distance W: 1 m (3.28ft)/ZFR/Z T: 2.5 m (8.20ft)//ZFR/Z
W: 2.5 m (8.20 ft)/Z4FR/Z4 T: 6 m (19.68 ft)/Z4FR/Z4
DORI Distance ZFR/Z
Lens Detect Observe Recognize Identify
W 60.1 m (187.19 ft) 24 m (78.74 ft) 12 m (39.37 ft) 6 m (19.69 ft)
T 128.6 m (421.92 ft) 51.4 m (168.64 ft) 25.7 m (84.32 ft) 12.8 m (41.99 ft)
Z4FR/Z4
Lens Detect Observe Recognize Identify
W 151 m (495.4 ft) 60.7 m (199.15 ft) 30.3 m (99.41 ft) 15.1 m (49.54 ft)
T 400 m (1312.34 ft) 160 m (524.93 ft) 80 m (262.47 ft) 40 m (131.23 ft)
Smart event
General IVS Analytics Abandoned object, moving object
Professional, intelligent
Perimeter Protection Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering.
Face Detection ZFR/Z4FR
1. Face recognition, track, priority, snapshot, face enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mask, beard 2.Face matting setting: face, single inch photo 3.Two snapshot strategies: priority snapshot, recognition 4.Face angle filter 5.Priority time setting 6.Management of 5 group face libraries 7. Single person register and person register in batch 8. Face recognition and similarity setting 9.Max supports face contrast in face library with 200,000 faces
Z4/Z
1.Face detection, track, priority, snapshot, face enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mask, beard Face matting setting: face, single inch photo Three snapshot methods: real-time snapshot, priority snapshot, quality priority 2.Face angle filter Priority time setting
ANPR Z4/Z
1.ANPR, track, priority, snapshot 2.Vehicle attributes: license plate, vehicle type, vehicle color,vehicle brand.3.Other attributes: sun visor, seat belt, smoking, phoning, in-car accessories, annual vehicle inspection mark
Video Metadata Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction.
People Counting People counting (count the entry number, exit number and pass number), display and output daily/monthly/annual statistics, No. in area
Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression H.265, H.264, H.264H, H.264B, MJPEG
Smart Codec Yes
Video Frame Rate Main Stream: 2688 × 1520 (1–50/60 fps)
sub stream 1: 704 × 576 (1–25/30 fps)
sub stream 2: 1920 × 1080 (1–25/30 fps)
sub stream 3: 1920 × 1080 (1–25/30 fps)
sub stream 4: 704 × 576 (1–25/30 fps)
Resolution 4M (2688 × 1520), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32–10240 kbps
H.265: 12–10240 kbps
Day/Night ICR switch
BLC Yes
WDR 140 dB
White Balance Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest(RoI) Yes (4 areas)
Electronic Image Stabilization(EIS) Yes
Smart IR Yes
Defog Yes
Image Rotation 0°/90°/180°/270° (Supports 90°/270° with 1080p resolution or below.)
Mirror Yes
Privacy Masking 4 areas
Audio
Audio Compression G.711a; G.711Mu; G726; AAC; G.723
Network
Network RJ-45 (10/100/1000 Base-T)
Protocol HTTP; Https; 8021.x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP; SFTP; RTMP; Genetec;Bonjour
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P
Scene self-adaptation Yes
User/Host 20
Edge Storage FTP; Micro SD card (256 G); NAS; SFTP
Browser IE: Versions later than IE9
Google: Versions later than Chrome 42
Firefox: Versions later than Firefox 48.0.2
Management Software Smart PSS, DSS PRO, NVR, IVSS, DMSS
Mobile Phone IOS, Android
Certification
Certifications CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Port
RS-485 1 (Bit rate: 1200 bps–115200 bps)
Audio Input Audio Interface: 1/1 channel In/Out
Audio Output
Alarm Input 3 channel In: 5mA 5V DC
Alarm Output 2 channel Out: 1000mA 30V DC/500mA 50V AC
Power
Power Supply 12V DC/24V AC/POE
Power Consumption Basic power consumption: 5.4W (12V DC); 5W (24V AC active power); 4.9W (POE);
Max power consumption (ICR switch, and IR full intensity): 16.7W (12V DC); 15.7W (24V AC active power); 15.6W (POE);
Environment
Operating Temperature -40°C to +60°C (-40°F to +140°F)
Operating Humidity 95%
Storage Temperature -40°C to +60°C (-40°F to +140°F)
Ingress Protection IP67, IK10
Structure
Casing Metal + Plastic
Dimensions 129.1 mm × Φ157.9 mm (5.08" × Φ6.22") (L × W × H)
Net Weight 1500 g (3.31lb)
Gross Weight 1600 g (3.53 lb)
Installation Ceiling Mount; side Mount; pole Mount

Related Prodcuts Models

IPC-HDBW7442H-ZFR

IPC-HDBW7442H-Z4FR

IPC-HDBW7442H-Z4

IPC-HDBW7442H-Z
